They are also designed to handle very high signal voltages up to 15 volts.
The BX-108Z is a powerful bass component.
** Picture to help illustrate input and outputs Setting the Bass Output Control
#Soundstream bx 108z installation install
(Dash Remote) – This is your knob, wait… you know what we mean?! Connect provide dash level controller and provided cable to install somewhere in drivers’ reach for adjustments. Make sure and measure and purchase separately to complete the installation (Output) – This should be connected to your bass amplifiers this kit does not come with any RCA cables. (Balanced Input) – Connect your Low-Level signal coming from your vehicle’s source unit or input converter if you are not using an aftermarket radio. ConnectionsĬonnect to amplifier Turn-On – Behind Radio or True Ignition Source On the Chassis of the BX-108Z, three LED indicators flash when the bass maximization circuit is activated. The Dash Mount Control has a LED indicator this LED will grow brighter as you add more bass or dim when you decrease the gain knob.īass Maximizer Indicator: Not only does the BX-108Z provide great music to your ears, but it gives you the same visual enjoyment as well. What that means in simple terms is that the BX-108Z will give more bass impact to your collection of music.īass Equalization Circuit: The BX-108Z has a unique equalization circuit that contours the restored bass to your speaker systems.ĭash Mount Remote Control: The BX-108Z comes with Dash Mountable Remote Control allows you to enjoy the effects of the BX-108Z without leaving the driver’s seat.
#Soundstream bx 108z installation manuals
The Width control then you can control the shape of the filter centered around the Sweep frequency.ħ.1 Related Manuals / Resources Product Featuresīass Restoration: The BX-108Z contains a Bass Restoration circuit that accurately injects Low-frequency information back into the signal path. The Sweep control allows you to select a center frequency ( the frequency most affected) between 27 and 63 Hz. However, the acoustics of various environments are different. The Bass Response is Effected by Four Factors:īecause of the variations in the recording process, we developed BX-108Z to help restore any low frequencies lost during the recording process. There’s a dash-mounted level control unit that permits instant adjustments, whether it’s because your passenger is not as much a “bass-head” as you are or, for whatever reason, you want to turn it down a bit this handy knob does the trick. Whether your interest is in Beethoven’s kettle drums, in Miles Davis’ trumpet, or the percussion of Rap music, the BX- 108Z will restore those long-lost missing bass with fantastic accuracy and clarity. You are now the proud owner of the most refined and most accurate bass enhancing & restoration system available. Congratulations on purchasing the SOUNDSTREAM BX-1O8Z.
